特征
- 完全符合当前行业标准
- 内阻极低，自动复位，快速跳闸
- 符合RoHS、Reach、HF、UL、C-UL、TUV
应用
- 智能手机
- 笔记本电脑
- 锂电池及充电电池组
- USB端口、Type-C端口、通讯端口
| P/N | IH(A) | IT(A) | Vmax(V) | I max(A) | T (Max time to trip) (A) |
T (Max time to trip) (Sec) |
Pd typ（W） | R min(Ω) | R max(Ω) | 规格书 |
| TLC-PSML400 | 4.00 | 9.00 | 6 | 50 | 20.0 | 2.00 | 1.20 | 0.002 | 0.026 | 下载 |
| TLC-PSML380 | 3.80 | 8.00 | 6 | 50 | 20.0 | 2.00 | 1.20 | 0.002 | 0.028 | 下载 |
| TLC-PSML350/12 | 3.50 | 7.00 | 12 | 50 | 17.5 | 2.00 | 1.20 | 0.003 | 0.030 | 下载 |
| TLC-PSML350 | 3.50 | 7.00 | 6 | 50 | 17.5 | 2.00 | 1.20 | 0.003 | 0.030 | 下载 |
| TLC-PSML300/12 | 3.00 | 6.00 | 12 | 50 | 15.0 | 2.00 | 1.20 | 0.003 | 0.030 | 下载 |
| TLC-PSML300 | 3.00 | 6.00 | 6 | 50 | 15.0 | 2.00 | 1.20 | 0.003 | 0.030 | 下载 |
| TLC-PSML260/12 | 2.60 | 5.20 | 12 | 50 | 8.00 | 5.00 | 1.20 | 0.006 | 0.035 | 下载 |
| TLC-PSML260/8 | 2.60 | 5.20 | 8 | 50 | 8.00 | 5.00 | 1.20 | 0.006 | 0.035 | 下载 |
| TLC-PSML260 | 2.60 | 5.20 | 6 | 50 | 13.0 | 2.00 | 1.20 | 0.003 | 0.035 | 下载 |
| TLC-PSML200 | 2.00 | 4.00 | 6 | 50 | 10.0 | 2.00 | 1.20 | 0.006 | 0.055 | 下载 |
| TLC-PSML175 | 1.75 | 3.50 | 6 | 50 | 8.00 | 2.00 | 1.20 | 0.010 | 0.060 | 下载 |
| TLC-PSML150 | 1.50 | 3.00 | 6 | 50 | 8.00 | 1.00 | 1.20 | 0.011 | 0.065 | 下载 |
| TLC-PSML125 | 1.25 | 2.50 | 6 | 50 | 8.00 | 5.00 | 0.70 | 0.010 | 0.160 | 下载 |
| TLC-PSML110 | 1.10 | 2.20 | 6 | 50 | 8.00 | 5.00 | 0.70 | 0.010 | 0.130 | 下载 |
| TLC-PSML100/12 | 1.00 | 2.00 | 12 | 50 | 8.00 | 1.00 | 1.20 | 0.018 | 0.110 | 下载 |
| TLC-PSML100 | 1.00 | 2.00 | 6.0 | 50 | 8.00 | 1.00 | 1.20 | 0.018 | 0.110 | 下载 |
| TLC-PSML075 | 0.75 | 1.50 | 6.0 | 50 | 8.00 | 1.00 | 1.20 | 0.020 | 0.160 | 下载 |
