特征
- 表面贴装产品，2920标准尺寸
- 适用于自动化机器批量贴装生产
- 符合RoHS、Reach、HF、UL、C-UL、TUV
应用
- 智能手机、平板电脑、数码相机、电脑主板
- USB端口保护、HDMI端口保护
-
汽车电子、安防设备
| P/N | IH(A) | IT(A) | Vmax(V) | I max(A) | T (Max time to trip) (A) |
T (Max time to trip) (Sec) |
Pd typ（W） | R min(Ω) | R max(Ω) | 规格书 |
| TLC-LSMD700 | 7.00 | 14.00 | 16 | 40 | 35.0 | 5.00 | 1.50 | 0.003 | 0.020 | 下载 |
| TLC-LSMD600 | 6.00 | 12.00 | 16 | 40 | 30.0 | 5.00 | 1.50 | 0.003 | 0.020 | 下载 |
| TLC-LSMD500/8 | 5.00 | 10.00 | 8 | 40 | 25.0 | 5.00 | 1.50 | 0.005 | 0.018 | 下载 |
| TLC-LSMD500 | 5.00 | 10.00 | 16 | 40 | 25.0 | 5.00 | 1.50 | 0.005 | 0.022 | 下载 |
| TLC-LSMD450 | 4.50 | 9.00 | 16 | 40 | 22.5 | 5.00 | 1.50 | 0.005 | 0.020 | 下载 |
| TLC-LSMD400 | 4.00 | 8.00 | 16 | 40 | 20.0 | 5.00 | 1.50 | 0.007 | 0.035 | 下载 |
| TLC-LSMD300/33 | 3.00 | 6.00 | 33 | 40 | 8.00 | 25.0 | 1.50 | 0.010 | 0.055 | 下载 |
| TLC-LSMD300/30 | 3.00 | 6.00 | 30 | 40 | 8.00 | 25.0 | 1.50 | 0.010 | 0.055 | 下载 |
| TLC-LSMD300D | 3.00 | 6.00 | 24 | 100 | 8.00 | 20.0 | 1.50 | 0.010 | 0.055 | 下载 |
| TLC-LSMD300D/16 | 3.00 | 6.00 | 16 | 40 | 8.00 | 25.0 | 1.50 | 0.010 | 0.055 | 下载 |
| TLC-LSMD300 | 3.00 | 6.00 | 12 | 40 | 8.00 | 25.0 | 1.50 | 0.010 | 0.055 | 下载 |
| TLC-LSMD260/33 | 2.60 | 5.20 | 33 | 40 | 8.00 | 20.0 | 1.50 | 0.014 | 0.080 | 下载 |
| TLC-LSMD260D | 2.60 | 5.20 | 24 | 100 | 8.00 | 18.0 | 1.50 | 0.014 | 0.075 | 下载 |
| TLC-LSMD260 | 2.60 | 5.20 | 16 | 40 | 8.00 | 20.0 | 1.50 | 0.014 | 0.075 | 下载 |
| TLC-LSMD250 | 2.50 | 5.00 | 16 | 40 | 8.00 | 16.0 | 1.50 | 0.018 | 0.085 | 下载 |
| TLC-LSMD200/33 | 2.00 | 4.00 | 33 | 40 | 8.00 | 4.50 | 1.50 | 0.020 | 0.125 | 下载 |
| TLC-LSMD200/24 | 2.00 | 4.00 | 24 | 40 | 8.00 | 4.50 | 1.50 | 0.020 | 0.120 | 下载 |
| TLC-LSMD200 | 2.00 | 4.00 | 16 | 40 | 8.00 | 4.50 | 1.50 | 0.020 | 0.120 | 下载 |
| TLC-LSMD185 | 1.85 | 3.70 | 33 | 100 | 8.00 | 2.0 | 1.50 | 0.030 | 0.150 | 下载 |
| TLC-LSMD150 | 1.50 | 3.00 | 33 | 40 | 8.00 | 2.0 | 1.50 | 0.035 | 0.230 | 下载 |
| TLC-LSMD125 | 1.25 | 2.50 | 33 | 40 | 8.00 | 2.0 | 1.50 | 0.05 | 0.250 | 下载 |
| TLC-LSMD110 | 1.10 | 2.20 | 33 | 40 | 8.00 | 0.50 | 1.50 | 0.065 | 0.410 | 下载 |
| TLC-LSMD100/60 | 1.00 | 2.00 | 60 | 100 | 8.00 | 0.50 | 1.50 | 0.090 | 0.410 | 下载 |
| TLC-LSMD100 | 1.00 | 2.00 | 33 | 40 | 8.0 | 0.5 | 1.5 | 0.065 | 0.410 | 下载 |
| TLC-LSMD075/60 | 0.75 | 1.50 | 60 | 40 | 8.0 | 0.3 | 1.5 | 0.100 | 1.000 | 下载 |
| TLC-LSMD075 | 0.75 | 1.50 | 33 | 40 | 8.0 | 0.3 | 1.5 | 0.100 | 1.000 | 下载 |
| TLC-LSMD050/50 | 0.50 | 1.00 | 50 | 10 | 2.5 | 3.0 | 1.5 | 0.180 | 1.400 | 下载 |
| TLC-LSMD050 | 0.50 | 1.00 | 60 | 10 | 2.5 | 1.0 | 1.5 | 0.180 | 1.400 | 下载 |
| TLC-LSMD030/50 | 0.30 | 0.60 | 50 | 10 | 1.5 | 3.0 | 1.5 | 0.600 | 4.300 | 下载 |
| TLC-LSMD030 | 0.30 | 0.60 | 60 | 10 | 1.5 | 3.0 | 1.5 | 0.600 | 4.300 | 下载 |
