特征
- 完全符合当前行业标准
- 内阻极低，自动复位，快速跳闸
- 符合RoHS、Reach、HF、UL、C-UL、TUV
应用
- 智能手机
- 笔记本电脑
- 锂电池及充电电池组
- USB端口、Type-C端口、通讯端口
| P/N | IH(A) | IT(A) | Vmax(V) | I max(A) | T (Max time to trip) (A) |
T (Max time to trip) (Sec) |
Pd typ（W） | R min(Ω) | R max(Ω) | 规格书 |
| TLC-LSML1000/24 | 10.0 | 20.0 | 24 | 50 | 50.0 | 7.00 | 1.50 | 0.0003 | 0.005 | 下载 |
| TLC-LSML1000/16 | 10.0 | 20.0 | 16 | 40 | 40.0 | 7.00 | 1.50 | 0.0003 | 0.005 | 下载 |
| TLC-LSML1000 | 10.0 | 20.0 | 6 | 40 | 40.0 | 7.00 | 1.50 | 0.0003 | 0.005 | 下载 |
| TLC-LSML900/24 | 9.0 | 18.0 | 24 | 50 | 45.0 | 7.00 | 1.50 | 0.0004 | 0.005 | 下载 |
| TLC-LSML750/24 | 7.50 | 15.0 | 24 | 50 | 37.5 | 7.00 | 1.50 | 0.0008 | 0.012 | 下载 |
| TLC-LSML750/12 | 7.50 | 15.0 | 12 | 50 | 37.5 | 7.00 | 1.50 | 0.001 | 0.013 | 下载 |
| TLC-LSML700/24 | 7.00 | 14.0 | 24 | 50 | 35.0 | 10 | 1.50 | 0.0008 | 0.012 | 下载 |
| TLC-LSML700/12 | 7.00 | 14.0 | 12 | 50 | 35.0 | 10 | 1.50 | 0.0008 | 0.012 | 下载 |
| TLC-LSML600/24 | 6.00 | 12.0 | 24 | 50 | 30.0 | 7.00 | 1.50 | 0.001 | 0.008 | 下载 |
| TLC-LSML600/16 | 6.00 | 12.00 | 16 | 50 | 30.0 | 7.00 | 1.50 | 0.001 | 0.008 | 下载 |
| TLC-LSML600/12 | 6.00 | 12.0 | 12 | 50 | 30.0 | 7.00 | 1.50 | 0.001 | 0.013 | 下载 |
| TLC-LSML500/24 | 5.00 | 10.0 | 24 | 50 | 25.0 | 7.00 | 1.50 | 0.001 | 0.012 | 下载 |
| TLC-LSML500/16 | 5.0 | 10.0 | 16 | 50 | 25.0 | 7.00 | 1.50 | 0.001 | 0.012 | 下载 |
