特征
- 完全符合当前行业标准
- 内阻极低，自动复位，快速跳闸
- 符合RoHS、Reach、HF、UL、C-UL、TUV
应用
- 智能手机
- 笔记本电脑
- 锂电池及充电电池组
- USB端口、Type-C端口、通讯端口
| P/N | IH(A) | IT(A) | Vmax(V) | I max(A) | T (Max time to trip) (A) |
T (Max time to trip) (Sec) |
Pd typ（W） | R min(Ω) | R max(Ω) | 规格书 |
| TLC-MSML900T/20 | 9.00 | 18.0 | 20 | 50 | 45.0 | 5.00 | 1.50 | 0.0005 | 0.007 | 下载 |
| TLC-MSML900T | 9.00 | 18.0 | 12 | 50 | 45.0 | 5.00 | 1.50 | 0.0005 | 0.007 | 下载 |
| TLC-MSML800 | 8.00 | 16.0 | 8 | 50 | 40.0 | 5.00 | 1.50 | 0.005 | 0.007 | 下载 |
| TLC-MSML750/21 | 7.50 | 15.0 | 21 | 50 | 37.5 | 5.00 | 1.50 | 0.0005 | 0.008 | 下载 |
| TLC-MSML750/12D | 7.5 | 15.0 | 12 | 50 | 37.5 | 5.00 | 1.50 | 0.0005 | 0.008 | 下载 |
| TLC-MSML750/12 | 7.5 | 15.0 | 12 | 50 | 37.5 | 5.00 | 1.50 | 0.0005 | 0.008 | 下载 |
| TLC-MSML750 | 7.5 | 15.0 | 6/8 | 50 | 37.5 | 5.00 | 1.50 | 0.0005 | 0.008 | 下载 |
| TLC-MSML500T | 5.0 | 10.0 | 24 | 50 | 25.0 | 5.00 | 1.50 | 0.001 | 0.010 | 下载 |
| TLC-MSML500/16 | 5.0 | 10.0 | 16 | 50 | 30.0 | 5.00 | 1.50 | 0.001 | 0.013 | 下载 |
| TLC-MSML500/12 | 5.0 | 10.0 | 12 | 50 | 30.0 | 5.00 | 1.50 | 0.001 | 0.013 | 下载 |
| TLC-MSML350/12 | 3.50 | 7.00 | 12 | 50 | 17.5 | 5.00 | 1.50 | 0.003 | 0.020 | 下载 |
| TLC-MSML300/24 | 3.00 | 6.00 | 24 | 50 | 15.0 | 5.00 | 1.50 | 0.003 | 0.030 | 下载 |
