特征
- 无铅/低内阻
- 抗振/无卤素
- 防电击外壳
应用
- 小家电、消费电子、汽车电子
- 充电器、变压器、电源适配器
- 仪器仪表、LED照明灯
| P/N | Rated current (A) |
Rated voltage (V) |
Maximun voltage drop (mv) |
Breaking capacity (A) |
I2T A2s | 规格书 |
| SETT20A250V | 20 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 400 | 下载 |
| SETT16A250V | 16 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 300 | 下载 |
| SETT15A250V | 15.0 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 295 | 下载 |
| SETT12.5A250V | 12.5 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 273 | 下载 |
| SETT12A250V | 12.0 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 272 | 下载 |
| SETT10A250V | 10.0 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 250 | 下载 |
| SETT8.0A250V | 8.0 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 215 | 下载 |
| SETT6.3A250V | 6.3 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 195 | 下载 |
| SETT5.0A250V | 5.0 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 148 | 下载 |
| SETT4.0A250V | 4.0 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 83.2 | 下载 |
| SETT3.15A250V | 3.15 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 72.9 | 下载 |
| SETT2.5A250V | 2.5 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 42.6 | 下载 |
| SETT2.0A250V | 2.0 | 250 | 100 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 21.9 | 下载 |
| SETT1.6A250V | 1.6 | 250 | 120 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 14.7 | 下载 |
| SETT1.25A250V | 1.25 | 250 | 130 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 12.8 | 下载 |
| SETT1.0A250V | 1.0 | 250 | 140 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 5.8 | 下载 |
| SETT0.80A250V | 0.800 | 250 | 160 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 3.9 | 下载 |
| SETT0.75A250V | 0.750 | 250 | 170 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 2.2 | 下载 |
| SETT0.63A250V | 0.630 | 250 | 180 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 1.2 | 下载 |
| SETT0.50A250V | 0.500 | 250 | 190 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 0.9 | 下载 |
| SETT0.40A250V | 0.400 | 250 | 200 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 0.5 | 下载 |
| SETT0.315A250V | 0.315 | 250 | 220 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 0.4 | 下载 |
| SETT0.25A250V | 0.250 | 250 | 240 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 0.3 | 下载 |
| SETT0.20A250V | 0.200 | 250 | 260 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 0.2 | 下载 |
| SETT0.16A250V | 0.160 | 250 | 280 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 0.1 | 下载 |
| SETT0.125A250V | 0.125 | 250 | 300 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 0.08 | 下载 |
| SETT0.10A250V | 0.100 | 250 | 350 | UL 100A@250Vac;TUV 120A@250Vac;VDE 35A@250Vac & 10In@250Vac | 0.06 | 下载 |
